SD-100-K INABA DENKO SLIMDUCT SD Lineset Cover 2 m (black)

INABA DENKO SLIMDUCT BLACK SD-100-K Lineset Cover 2 m

The INABA DENKO SLIMDUCT SD-100-K straight duct provides a 2 m protective covering for air conditioning and heat pump service lines. Its larger 100 × 70 mm profile offers practical internal space for insulated refrigerant pipes, condensate drainage and electrical wiring while keeping exposed HVAC services neatly organised and concealed.

Designed as part of the SLIMDUCT SD trunking system, the SD-100-K can be combined with matching elbows, couplers and other fittings to create a continuous pipe covering route. The 2 m straight duct is particularly suitable for longer installation runs where fewer connections are preferred, while multiple sections can be joined when additional length is required.

The black decorative lineset cover provides a coordinated finish for darker façades, walls and architectural surfaces. Black trunking sections are supplied with a protective film, helping prevent scratches and surface damage before installation and preserving the appearance of the finished duct.

For longer straight routes, additional SD-100-K sections can be connected using the matching SJ-100-K duct coupler, while compatible SLIMDUCT SD-100 fittings allow the trunking route to be adapted around corners and changes in direction.

CLEAN AND ORGANISED HVAC TRUNKING SYSTEM

Keeps refrigerant pipes, condensate drain lines and electrical wiring concealed within a neat, organised trunking route for a professional HVAC installation. The protective cover also helps reduce exposure to UV radiation, weather conditions and accidental damage, while maintaining a clean finished appearance.

KEY FEATURES

• Black lineset cover for air conditioners and heat pumps
• 100 × 70 mm straight duct for HVAC service lines
• Length: 2 m
• Colour: Black (RAL 9011)
• Helps conceal and protect refrigerant pipes, drain lines and electrical wiring
• UV-resistant and water-resistant for reliable indoor and outdoor installation
• Punch-out mounting holes every 100 mm for quick and convenient installation
• Anti-slip design helps prevent trunking components from sliding out of position
• Protective film helps prevent scratches and damage before installation
• Part of the SLIMDUCT SD decorative trunking system
• Compatible with SLIMDUCT SD-100 fittings and accessories
• Multiple sections can be joined using the SJ-100-K duct coupler for longer installation runs
• Suitable for indoor and outdoor installation
• Operating temperature: −20 °C to +60 °C

LIMDUCT SD VS TAPING – LONG-TERM PROTECTION

SLIMDUCT SD protects refrigerant pipes, insulation, drain hoses and cables from UV exposure, rain and weather conditions, helping the installation remain clean, protected and professional-looking for years.

With taping installation, prolonged exposure to sunlight and weather can cause the wrapping to deteriorate, discolour, crack and peel, leaving the pipework and insulation increasingly exposed.

PIPE CAPACITY

For insulated copper pipes with 10 × 10 mm insulation:

1/4″ × 3/8″ — up to 2 sets
1/4″ × 1/2″ — 1 set
1/4″ × 5/8″ — 1 set
3/8″ × 5/8″ — 1 set
3/8″ × 3/4″ — 1 set
3/8″ × 7/8″ — 1 set

PROTECTIVE FILM

SLIMDUCT Black trunkings come with a protective film to eliminate any possibility of scratches or damages before using.

PUNCH-OUT HOLES FOR EASY INSTALLATION

Pre-punched mounting holes every 100 mm allow quick and convenient screw fixing for easier SLIMDUCT SD installation.

ANTI-SLIP PIN FITTINGS

Selected fittings feature a hook pin that helps keep the cover securely in position and prevents it from sliding off.

APPLICATIONS

The SD-100-K decorative lineset cover is suitable for residential and commercial air conditioning and heat pump installations where larger refrigerant pipework and associated HVAC services require an organised protective covering.

The 2 m straight duct is well suited to extended pipe routes and can accommodate insulated copper refrigerant pipes, condensate drainage and electrical wiring. Together with compatible SLIMDUCT SD-100 components, it forms a modular decorative trunking system that provides a clean and continuous finish across the installation.

5 COLOUR VARIETIES

White RAL 9003 Ivory RAL 7044 Anthracite Grey RAL 7016 Brown RAL 6014 Black RAL 9011

MORE ABOUT SLIMDUCT SD

SLIMDUCT SD Trunking System Catalogue
